inline-testing tool | fully automated measurement & handling of ingots, boules or panels
Ready for integration for any automation or processing system
Designed for harsh environments (grinding, sawing)
Compact, standard industrial interfaces
Independent orientation measurement
Measurements on flat surface or circumferences
Optical notch detection
measurable materials: Si, SiC, GaAs and many more
sample size: ingots up to 450 mm diameter
cooling: air, low noise
possible applications: pre-alignment of large ingots prior to sawing/grinding | flat/notch detection
Orientation of silicon ingots:
detection of flat and notch position prior to grinding
diameter up to 8''
length up to 40 cm
