Materials

With DDCOM, a wide variety of materials can be precisely analyzed. Thanks to their flexibility and performance, our systems meet even the most demanding requirements.

Ag Al₂O₃ (sapphire) AlSb Au CdTe GaAs GaN GaP GaPO₄ GaSb Ge InAs InP InSb La₃Ga₅SiO₁₄ LaTiO₃ LiF LiNbO₃ Mg₂SiO₄ MgAl₂O₄ MgF₂ MgO NdGaO₃ Ni PbS PbTe Pt Si SiC 2H SiC 4H SiC 6H SiC 15R SiC₃C SiO₂ (quartz) SnTe SrLaAlO₄ SrTiO₃ TiO₂ ZnO ZnTe and more

Features & Benefits

Ultra-fast Omega-scan approach

  • 200 times faster than Theta-scan method

  • Automatic evaluation of the complete lattice orientation in 3D

  • Determination of entire crystal orientation within 5 seconds

Efficient workflows for quality control

  • For standard research and industrial workflows

  • Azimuthal setting and marking of crystal orientation

  • Preprogrammed cubic crystal parameters

  • State-of-the-art and convenient software

  • High precision, i.e up to (1/100)°

Compact, user friendly and cost effective

  • Easily movable and lightweight desktop design

  • Convenient sample handling and easy to operate

  • Low energy consumption and operating costs due to air cooled X-ray tube (no water cooling required)

Control of cutting, grinding and lapping

  • Complete lattice orientation of single crystals

  • Suitable for a unique variety of materials in a large range of size and weight, such as: Wafers from 2-12” and Ingots up to 20kg


Highlights

  • Determination of the complete lattice orientation of single crystals

  • Ultra-fast crystal orientation measurement using the Omega-scan method

  • Determination of the arbitrary unknown orientation of cubic crystals

  • Designed especially for azimuthal setting and marking of lattice directions

  • Air cooled X-ray tube, no water cooling required

  • Appropriate for research and production quality control

DDCOM – Exclusively through Malvern Panalytical

This product is distributed by our trusted partner.

Contact for demo

Technical specifications

X-ray source30 W air-cooled X-ray tube, Cu anode
DetectorsTwo scintillation counters
Sample holderPrecise turntable, setting accuracy 0.01°, tools for defined sample positioning and marking
Dimensions600 mm × 600 mm × 850 mm
Weight80 kg
Power supply100-230 V, 100 W, single phase
Room temperature≤ 30° C

Accessories & Options

  • Device for mapping of wafers (maximum diameter 225 mm)

  • Device for automatic loading from cassettes
