Built for routine, ready for research
Modular instrument configuration
No stimulation or irradiation crosstalk
Two removable 40-position carousels allowing true 24/7 operation
Features & Benefits
Applications
With lexsygsmart, we’ve created a compact system that gives laboratories the flexibility they need – combining reliable high-performance measurements with straightforward operation.
Dipl.-Ing. Andreas Richter
Senior Product Manager TL/OSL
Capabilities that enable research
| System Design | Compact, space-efficient system optimized for routine and standard measurements |
|---|---|
| Sample Handling | Two removable 40-position carousels allowing true 24/7 operation |
| Detection Configuration | Fixed single detector position with a PMT |
| Thermal Stimulation | From room temperature up to 710 °C, programmable heating and cooling, rates 0.1 – 20 °C/s |
| Peltier Cooling | Available on lexsygresearch |
| Optical Stimulation Sources | High-power LEDs / laser diodes
|
| OSL Measurement Modes | CW-OSL, LM-OSL, POSL |
| Pulsed OSL | 10 μs standard |
| Irradiation Sources | Single source (Beta or X-ray) |
| Photomultiplier Tubes (PMTs) | Wide spectral coverage 160 – 1200 nm (UV–NIR) with specialized PMT options |
| Detection Filter Wheels | Single 6-position filter wheel (8 mm max. filter thickness) |
| IRPL Detection | 880 nm and 955 nm emissions |
| Bleaching Options | OSL unit with built-in UV-LED (365 nm) or IR LED (850 nm) |
| Single-Grain Analysis | Available on lexsygresearch |
| Emission Spectroscopy | Available on lexsygresearch |
| Radioluminescence (RL) | Beta or X-ray irradiation; detection with PMT (180 – 890 nm) |
| X-ray Fluorescence (XRF) | Available on lexsygresearch |
| Sample Checking | Available on lexsygresearch |
| Power Requirements | 110 – 250 V AC, 10 A |
| Dimensions & Weight | 300 × 420 × 350 mm, ≥ 50 kg |
| Control Computer | Windows® 11 or newer with two Ethernet ports (for system operation & remote support) |
